CCE Triangle bag tea packaging machine

Production speed: 35 ~ 50 bags / min

Gram weight range: 1≤50 ± 0.5g / bag (customizable)

Material requirements: material length ≤ 15mm, otherwise the weighing accuracy will decrease

Applicable materials: nylon membrane, non-woven fabric, corn fiber

Air source pressure: ≥0.6Mpa

Motor power: 1.1Kw (220V)

Equipment appearance: L800 × W700 × H2000 (mm)

Equipment weight: 300KG

Scope of application: Nylon triangle packaging machine is an automatic precision equipment that can be used for triangle three-dimensional packaging of granules such as flower tea, green tea, black tea, slimming tea, health tea, herbal tea, babao tea, schisandra, etc., widely used in food, medicine and other industries package of.

Performance characteristics:

Ultrasonic sealing and cutting can be used for flat bag packaging, triangle three-dimensional packaging and other forms; the whole machine can automatically complete the functions of feeding, measuring, bag making, sealing, cutting, counting, etc .;

A precise control system is used to adjust the movement of the whole machine, the bag length is stable, the positioning is accurate, and the machine is convenient to adjust; according to the packaging materials, electronic scale measurement and volume method measurement (measuring cup type measurement) can be selected;
