♦ Usage
Suitable for automatic packaging powder materials like all kinds of flour ,washing powder, fine sugar, milk powder, glucose, seasoning, food additive,pesticide,and Chinese medicine.
♦ Features
1.Imported PLC control system, simple-operating, visual touch screw.
2.Servo film feeding system, correct register, sealing and cutting positions adopt automatic correction device, high automation.
3.Intelligent temperature controller is used, correct temperature control, ensure nice, smooth seal.
4.Perfect automatic alarming protective function, reduce the consumption up to the lowest.
5.When the machine is combined with metering equipments, full packaging process including automatic feeding, metering, bag filling, date printing and automatic counting is completed.
6.Type of bag making: according to customer's demand, the machine can produce pillow bags, punched hang
Packing speed
15-50bags/min
Bag-making size
(L)80-300mm(W)80-200mm
Filling range
10-1000g
Film width
180-420mm
Packing materials
OPP/CPP PET/PE PET-AL/PE
Film thickness
0.04-0.08mm
Air consumption
0.36m3/min 0.6MPa
Power supply
AC220V/380V 50/60Hz 3.5kw
Machine dimensions
(L)1750×(W)1050×(H)2580mm
Machine weight
580kg
