Summarize:
This machine is applicable for encasing ointment，injection and vial etc automatically.The working process is product conveying，leaflet conveying (1-4 fold)，carton opening and conveying, box and leaflet encasing，meanwhile finish auto batch coding and carton sealing. (Hot melt glue device as option)
Main technical parameter:
|
Electric power
|
AC220V 50HZ motor power
0.75KW
|
|
Production capacity
|
Rotation speed 30-100b/min
|
|
Volume of consumption
|
120~160L /min
(pressure0.5-0.8Mpa)
|
|
Packing material
|
Box requirement:250-350g/m2
(according to its dimensions to confirm)
|
|
Specifications:
Max.Size(LxHxW)200x80x50mm
|
|
Min.Size(LxHxW):50x20x14mm
|
|
Leaflet
|
Paper requirement:55-65g/m2
|
|
Specifications:
Max.Size:240x190mm(LxW)
|
|
Min.Size:80x90mm(LxW)
|
|
Overall dimension
|
3100x1100x1600mm
|
|
Machine Weight
|
about l.5T
|
Q1:Are you a trading company or manufacture?
A1: GF is a professional trading company with some experience manufacturers over years. Your order will be controlled from very beginning to the last.
Q2: What is your delivery time?
A2: Normally 30-45 days upon order confirmation.
Q3: What is your packing pattern?
A3: Special export wooden packing
Q4: How about your service?
A4:Engineers available to service machinery overseas
Q5: How about your product?
A5: We have the standard production and complete quality control system to ensure high quality
products. Our products get ISO. CE.SGS.IAF
Q6:How to choose the machine type for our bags?
A6: Pls support us the following information about the bag and the food.
1) bag pattern
2)bag size
3)the filling weight or volume
4)material of food: powder/liquid/paste/granular/massiveness
5)sample bags or pictures
1.Round the Clock Customer Service Centers
2.Skilled Maintenance Team, Engineers Available to Service Machinery Overseas.
3.Expert Team, Technical Support
4.Abundant Spare Parts, Swift Storage Center
