Summarize:
ZH-200 Automatic High-speed Cartoning Machine was modified based on the similar imported machine with our own innovations characteristic of pneumatic-photo-electro-mechanic integration with high performance and complies with GMP requirements. The machine runs successivelyand horizontally with max. capacity of 200 boxes/min including automatic box open, leaflet folding, embossing, sealing, detection and rejection, etc. lt's suitable for packing blisters, tubes, bottles and similar shape of goods like in pharmaceutical, food, cosmetics, chemical and hardware inductry. It can also be linked with Blister Packing Machine, Filling Machines Shrink Machine, Three-Dimensional Packaging Machine or Box Machine to form a production chain.
Main technical parameter:
|
Encasing speed
|
120-200(box/min)
|
|
Box
|
Quality requirement:250-350g/m2
|
|
Dimension range(LxWxH):(50-220) x
(20-90) x (14-70)(mm)
|
|
Leaflet
|
Quality requirement :50-65g/m2
|
|
Unfolded leaflet specification
:(LxW):(80-300)x( 70-210)mm
|
|
Folded leaflet
specification(l-4):(LxW):(70-21 0)x(20-40)mm
|
|
Compressed air
|
Working pressure:0.5-0.7mpa
|
|
Air consumption:6.Om3 /h
|
|
Power supply
|
380V 50HZ
|
|
Motor power
|
2kw
|
|
Overall dimension
|
4010x1200x1700mm
|
|
Weight
|
About 2500kgs
|
Q1:Are you a trading company or manufacture?
A1: CCE is a professional trading company with some experience manufacturers over years. Your order will be controlled from very beginning to the last.
Q2: What is your delivery time?
A2: Normally 30-45 days upon order confirmation.
Q3: What is your packing pattern?
A3: Special export wooden packing
Q4: How about your service?
A4:Engineers available to service machinery overseas
Q5: How about your product?
A5: We have the standard production and complete quality control system to ensure high quality
products. Our products get ISO. CE.SGS.IAF
Q6:How to choose the machine type for our bags?
A6: Pls support us the following information about the bag and the food.
1) bag pattern
2)bag size
3)the filling weight or volume
4)material of food: powder/liquid/paste/granular/massiveness
5)sample bags or pictures
1.Round the Clock Customer Service Centers
2.Skilled Maintenance Team, Engineers Available to Service Machinery Overseas.
3.Expert Team, Technical Support
4.Abundant Spare Parts, Swift Storage Center
